HK Porter

HK Porter aerospace ducting is used on a wide range of GA aircraft and Airliners.

Aeroduct CAT, SCAT, CEET and SCEET ducting types are capable of handling some of the most extreme needs in the aviation industry.

CAT and CEET feature fiberglass fabrics impregnated and coated with neoprene. They have an operating temperature of -65°F (-54°C) to +350°F (177°C). CAT is an excellent choice for low-pressure air and fume moving requirements where exceptional flexibility is important. CEET’s lined construction provides excellent air flow even when tight bends and cramped quarters are a concern.

SCAT and SCEET offer fiberglass fabrics impregnated with silcone. This gives both styles a wide temperature range of -80°F (-62°C) to +550°F (288°C). SCAT is extremely flexible, perfect for negotiating tight bends and obstructions. SCEET, like CEET, offers superior air flow and low air friction loss with a lined construction

SCAT and SCEET

Standard length: 11ft

SCAT (Single Layer) Part Number	SCEET (Double Layer) Part Number	Inside Diameter (Inches)
SCAT4	SCEET4	1
SCAT5	SCEET5	1-1/4
SCAT6	SCEET6	1-1/2
SCAT7	SCEET7	1-3/4
SCAT8	SCEET8	2
SCAT9	SCEET9	2-1/4
SCAT10	SCEET10	2-1/2
SCAT11	SCEET11	2-3/4
SCAT12	SCEET12	3
SCAT13	SCEET13	3-1/4
SCAT14	SCEET14	3-1/2
SCAT15	SCEET15	3-3/4
SCAT16	SCEET16	4
SCAT18	SCEET18	4-1/2
SCAT20	SCEET20	5
SCAT22	SCEET22	5-1/2
SCAT24	SCEET24	6

CAT and CEET

Standard length: 10ft

CAT (Single Layer) Part Number	CEET (Double Layer) Part Number	Inside Diameter (Inches)
CAT4	CEET4	1
CAT5	CEET5	1-1/4
CAT6	CEET6	1-1/2
CAT7	CEET7	1-3/4
CAT8	CEET8	2
CAT9	CEET9	2-1/4
CAT10	CEET10	2-1/2
CAT11	CEET11	2-3/4
CAT12	CEET12	3
CAT13	CEET13	3-1/4
CAT14	CEET14	3-1/2
CAT15	CEET15	3-3/4
CAT16	CEET16	4
CAT18	CEET18	4-1/2
CAT20	CEET20	5
CAT22	CEET22	5-1/2
CAT24	CEET24	6
