Specifications

Duration of Use

  • 15 minutes against the workload specified in TSO C-116
  • Up to 60 minutes for a person sitting awaiting rescue
Donning Time
  • 15 seconds (max)
Oxygen Activation
  • Automatic upon donning
Service & Shelf Life
  • 10 years and 6 months
Sizing and Fitting
  • Fits 5 – 95% adults without adjustments
Visibility
  • Able to read an exit sign at 16 feet with maximum misting
Oral Communication
  • Effective at 13 feet and is compatible with aircraft intercom
Inside Hood Temperature
  • 104°F (40°C) at 68°F (20°C) ambient
Stowage Temperature Range
  • From 185° F (85°C) to -20° F (-29°C)
Working Temperature Range
  • From 120°F (49°C) to 5°F (-15°C)
Thermal Resistance
  • Radiant Heat: 1.0 BTU / ft² for up to 60 seconds
  • Dripiping thermoplastics: 390°F (199°C)
  • Transient Flame: 1,800°F (985°C) for 5 seconds
Protection Factor (Typical) at 80 Watts
  • Over 300
Method of Inspection
  • Visual
Source of Breathable Air
  • 2 Bottles of 100% aviators grad compressed oxygen
  • Bottles have over pressure protection to prevent rupture
Carbon Dioxide Control
  • Patented Passive Scrubber
Materials of Construction
  • The patented hood is made from multiple layers of PFA film and Polymide film
  • Polymide film for high heat resistance
  • The patented neck seal is made from a very elastic, high strength silicone
Packaging
  • Broad range of standard containers and pouches
Weight
  • Vacuum pouch alone: 3.2lbs
Size
  • Barrier Pouch (non compact): 9.75″x12″x1.75″
  • Stowage option will affect final size
