Tempest Oil Filters

Tempest™ Original filters are the only aviation oil filters made in a dedicated manufacturing plant.

Features and Benefits:

  • Magnetic Filtration System – In addition to the largest filter media area, Tempest™ Original filters have an internal magnet to catch the particles that pass through the filter.
  • Six-pack - Tempest™ Original filter are available in a convenient and economical six-pack.
  • Improved Nut Welds – The nut welds on Tempest™ Original filters are strong enough to withstand the can distorting and even breaking without failing.
  • Meets TCM bypass Specification (12-14psi) – Reduces risk of unexpected bypass to avoid unfiltered oil reaching the engine.
  • Burst Strength of 600psi – Improvements to the seam process used on the bottom of the can mean Tempest™ Original filters exceed ARP 1400 standards by 50%.
  • Non-Stick Gaskets – Synthetic rubber gaskets ensure Tempest™ Original filters maintains proper torque during installation and removal.

Oil Filter Specifications





Filter Model Overall Dimensions Thread Size & Type Installation Torque




AA48103 4-7/8 H x 3-3/4 dia. 13/16-16 Female 16-18 ft lbs
AA48104 6-3/16 H x 3-3/4 dia. 13/16-16 Female 16-18 ft lbs
AA48108 4-7/8 H x 3-3/4 dia. 3/4-16 Female 16-18 ft lbs
AA48109 6-3/16 H x 3-3/4 dia. 3/4-16 Female 16-18 ft lbs
AA48110 4-7/8 H x 3-3/4 dia. 3/4-16 Female 16-18 ft lbs
AA48111 6-3/16 H x 3-3/4 dia. 3/4-16 Female 16-18 ft lbs




Application Guide
